BG100 TI (BG100 TI)
BG100 TI - Primary View
Boom Barriers
Entrance Control
Standalone Product
In Stock

BG100 TI

Model: BG100 TI  ·  SKU: MM-eSSL-BG100-TI

Brand: eSSL  ·  Warranty: 1 Year

The BG100 TI (BG100 TI) is a boom barriers terminal from eSSL — eSSL BG100 TI is a 5-metre bending-arm boom barrier with a 2.5 m straight section and 2.5 m bending section. It has an aluminium arm, 6-second opening/closing time, IP55 protection, automatic/manual operating modes, dry-contact control and interfaces for photocell, air switch and optional access-control equipment.

Brand
eSSL
Product type
Standalone Product
Sold by
MegaMind Technosoft
Category
Boom Barriers
Recognition speed
6 sec up/down
Availability
In Stock
Warranty
1 Year

Key Features — BG100 TI

  • 5 m maximum bending boom (2.5 m straight + 2.5 m bending)
  • Aluminium arm with boom-rest stand
  • 6-second up/down time
  • Automatic / manual operation
  • IP55 protection
  • Dry-contact control
  • Photocell and air-switch inputs
  • Alarm-lamp output
  • Optional access-control panel, standalone access control and control button
  • Remote control up to 25 m
  • STOP / UP / DOWN control buttons
  • Optional bumping bounce-back
  • 1–99 second auto-closing
  • Manual release and double safety limit switches
  • Intensive duty cycle, MCBF 30 lakh
  • Optional traffic-light interface
  • Wiegand, RFID and biometric compatibility
  • Optional infrared photocell for anti-bumping
Get Quote
+91-9818442254WhatsAppCompare
Share:WhatsApp

Product Overview

The eSSL BG100 TI is a bending-arm barrier designed for vehicle entry and exit control where the physical layout requires a bending boom configuration. eSSL specifies a maximum boom length of 5 m, configured as 2.5 m straight + 2.5 m bending, with an aluminium arm and a published up/down time of 6 seconds.

The barrier supports automatic and manual operation and uses a dry-contact input control signal. The official specification lists an IP55 ingress-protection rating, photocell and air-switch inputs, alarm-lamp output, and optional interfaces for an access-control panel, standalone access control and control button.

The BG100 TI also includes an incorporated control panel with three push buttons for STOP / UP / DOWN, an optional bumping bounce-back function, automatic closing from 1–99 seconds, manual release and double safety limit switches. eSSL additionally lists compatibility with Wiegand, RFID readers and biometric systems.

What Is BG100 TI?

eSSL BG100 TI is a bending-arm boom barrier with a maximum 5 m boom consisting of a 2.5 m straight section and a 2.5 m bending section.

Software & Integration

The BG100 TI integrates with photocells, air switches, access-control panels and BB-Radar for parking access control deployments, and is compatible with Wiegand, RFID and biometric systems.

Applications

Typical deployments for the BG100 TI: - Residential society vehicle gates - Apartment and villa entrances - Corporate parking - Industrial premises - Office campuses - Vehicle-controlled entry and exit points - Sites where a bending-arm barrier configuration is useful

Ideal for — BG100 TI

CorporateResidentialBoom Barriers catalog
Verified Datasheet43 specifications • 2 categories

Technical Specifications

Detailed hardware, electrical, network, and operational specifications for BG100 TI (BG100 TI).

Download PDF Datasheet

Power & Control

1 spec
Power Supply
AC 220V / 110V, 50Hz / 60Hz

Additional Specifications

42 specs
Boom Configuration
2.5 m straight + 2.5 m bending
Boom Rest Stand
Yes
Time for Up / Down
6 sec
Input Control Signal
Dry contact
Ingress Protection
IP55
Input Interfaces
Photocell, air switch
Output Interface
Alarm lamp
Remote Control
Up to 25 m
Operating Mode
Automatic / manual
Control Panel
STOP / UP / DOWN
Bumping Bounce Back
Optional
Auto Closing Time
1–99 sec
Power Input
AC 220V / 110V, 50Hz / 60Hz
Motor Power
90W, 240V AC
Traffic Light Interface
Optional
Maximum Boom Length
5 m (2.5 m straight + 2.5 m bending)
Recognition Speed
6 sec up/down
Operating Temperature
-20°C to +50°C
Device Type
Automatic / manual bending arm boom barrier
Protection
IP55
Wi-Fi
No
TCP/IP
No
LAN Interface
No
USB Port
No
Wiegand Interface
No
PoE Support
No
Battery Backup
No
Arm Type
Bending
Max Boom
5 m (2.5 m straight + 2.5 m bending)
Arm Material
Aluminium
Up Down Time
6 sec
Control Signal
Dry contact
Interfaces
Photocell, air switch, alarm-lamp output
Optional Interfaces
Access-control panel, standalone access control, control button
Remote Range
Up to 25 m
Operation Mode
Automatic / manual
Auto Closing
1–99 sec
Motor
90W, 240V AC
Temperature
-20°C to +50°C
Duty Cycle
Intensive
Mcbf
30 lakh
Traffic Light
Optional

How to choose the right Boom Barriers device

Every boom barriers requirement is different. Before you buy BG100 TI, compare these points — they are the same checks our engineers use when recommending boom barriers attendance and access solutions to Indian businesses.

Size it to your site

  • Recognition speed of 6 sec up/down

What to look for in a Boom Barriers

  • Compare max gate weight (kg) against your actual workload
  • Compare lift height (m) against your actual workload
  • Compare torque against your actual workload
  • Check Simultaneous Operation is built in if your site needs it
  • Compare power supply against your actual workload
  • Compare communication against your actual workload
  • Compare control options against your actual workload
  • Compare accessories against your actual workload

Service, warranty & software

  • Warranty: 1 Year — confirm claim process and turnaround
  • Works with MegaMind Attendance software for shifts, payroll export and reports
  • Pan-India installation, training and AMC support from certified engineers
  • Availability: In Stock — confirm lead time with your quote

Connectivity & integration

  • API and SDK support for custom HRMS, ERP and payroll integration

Applications — BG100 TI

Industries and use-cases where the BG100 TI is commonly deployed.

  • Residential society vehicle gates
  • Apartment and villa entrances
  • Corporate parking
  • Industrial premises
  • Office campuses
  • Vehicle-controlled entry and exit points
  • Sites where a bending-arm barrier configuration is useful
