C3-200
Model: C3-200 · SKU: MM-eSSL-C3-200
Brand: eSSL · Warranty: 1 Year
The C3-200 (C3-200) is a access control terminal from eSSL — The eSSL C3-200 is a two-door access-control panel supporting up to 30,000 card holders and 100,000 log events. It provides TCP/IP and RS-485 communication, supports up to four readers, six inputs and four relay outputs, and is designed for wall-mounted access-control installations.
- Brand
- eSSL
- Product type
- Standalone Product
- Sold by
- MegaMind Technosoft
- Category
- Access Control
- Card capacity
- 30,000
- Connectivity
- TCP/IP
- Availability
- In Stock
- Warranty
- 1 Year
Key Features — C3-200
- 2-door access-control controller
- 30,000 card-holder capacity
- 100,000 log-event capacity
- TCP/IP communication
- RS-485 communication
- 4 reader interfaces
- 26-bit Wiegand reader support
- Other reader types upon request
- 2 exit-device inputs
- 2 door-status inputs
- 2 auxiliary inputs
- 2 Form-C lock relays
- 2 Form-C auxiliary relays
- Built-in auxiliary input/output capability
- Wall mounting
- Powder-coated aluminium enclosure
- 12V DC / 1.5A recommended supply
- Access Security System 3.5 support
- MS Access / MS SQL database support
Product Overview
The C3-200 is a two-door access-control controller designed to manage access across two controlled doors. The current eSSL product page specifies 30,000 card holders and 100,000 log events.
The controller supports TCP/IP and RS-485 communication. eSSL specifies four reader interfaces and identifies 26-bit Wiegand as the standard reader type, with other reader types available upon request.
The published input configuration is six inputs, consisting of two exit-device inputs, two door-status inputs and two auxiliary inputs. Four outputs are specified, comprising two Form-C lock relays and two Form-C auxiliary relays.
The controller uses a powder-coated aluminium enclosure and wall mounting. eSSL recommends a 12V DC / 1.5A power supply.
The C3-series documentation also describes the auxiliary inputs as suitable for devices such as infrared detectors, fire alarms and smoke detectors, while auxiliary outputs can be connected to alarms, cameras and door bells.
What Is C3-200?
C3-200 is a two-door eSSL access-control panel.
Software & Integration
The C3-200 is supported by Access Security System 3.5 with MS Access / MS SQL databases and is part of the C3 controller family, whose manual documents time zones, access levels, anti-passback, interlock, linkage, multi-card opening, remote door opening/closing and browser-based real-time monitoring at family level. Integrates with MegaMind Attendance and MegaMind HRMS access-control deployments.
Applications
Typical deployments for the C3-200: - Offices - Factories and manufacturing units - Hotels - Hospitals - Apartment buildings - Universities and campuses - Government and public buildings - Other restricted-access facilities
Ideal for — C3-200
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for C3-200 (C3-200).
Verification
| Card Capacity (cards) | 30,000 |
|---|
Interface
| Communication | TCP/IP + RS-485 |
|---|---|
| Wiegand | 26-bit Wiegand |
Power & Environment
| Power Supply | 12V DC, 1.5A (recommended) |
|---|---|
| Dimensions | Not published in current main specification |
Additional Specifications
| Number of Readers Supported | 4 |
|---|---|
| Weight — Main Specification | 7.5 lb / 3.4 kg |
| Type | 2-door access control panel |
| Event Capacity | 100,000 |
| Reader Protocol | 26-bit Wiegand |
| Enclosure Material | Powder-coated aluminium |
| Mounting Type | Wall mount |
| Weight | 7.5 lb / 3.4 kg (main specification) |
| Database | MS Access / MS SQL |
| Card Holder Capacity | 30,000 |
| Log Event Capacity | 100,000 |
| Other Reader Types | Upon request |
| Exit Device Inputs | 2 |
| Door Status Inputs | 2 |
| Auxiliary Inputs | 2 |
| Lock Outputs | 2 Form-C relay |
| Auxiliary Outputs | 2 Form-C relay |
| Enclosure | Powder-coated aluminium |
| Recommended Power Supply | 12V DC / 1.5A |
| Weight Main Spec | 7.5 lb / 3.4 kg |
| Source Conflict | Current eSSL webpage contains duplicated/contradictory technical blocks; port architecture verified against C3-Series User Manual. |
Hardware & Controller Interfaces
| Door Count | 2 |
|---|---|
| Reader Count | 4 |
| Input Count | 6 |
| Output Count | 4 |
| Mounting | Wall mount |
Access Control Software & Features
| Supported Software | Access Security System 3.5 |
|---|
