D270-1-IP54
Model: D270-1-IP54 · SKU: MM-eSSL-D270-1-IP54
Brand: eSSL · Warranty: 1 Year
The D270-1-IP54 (D270-1-IP54) is a dfmd terminal from eSSL — eSSL D270-1-IP54 is an IP54-based single-zone walk-through metal detector with an ABS body, 0–400 adjustable sensitivity, 15 alarm tones, infrared pass/alarm counting and glowing LED zone indication.
- Brand
- eSSL
- Product type
- Standalone Product
- Sold by
- MegaMind Technosoft
- Category
- DFMD
- Availability
- On Request
- Warranty
- 1 Year
Key Features — D270-1-IP54
- Ergonomic structure, new design
- High-brightness LED digital display with zone indication
- Detection shown by glowing LED indication from top to bottom on single zone
- Easy fixing of cross beams with side-door DFMD controller
- Infrared sensor for pass count & alarm count
- Single-zone detection
- 0–400 adjustable sensitivity
- 0–50 adjustable volume
- 0–3 sec alarm volume
- 15 different alarm tones
- Ferrous metal detection
- ABS (Acrylonitrile Butadiene Styrene) construction
- Simple installation — 2 doors (R & L), cross beam with wire probe
Product Overview
The eSSL D270-1-IP54 is an IP54-based single-zone metal detector designed for entry screening and detection of prohibited metallic items. The official eSSL specification identifies its working principle as Electromagnetic, built from ABS raw materials.
The published technical specification lists net weight of 21 kg (gross 27 kg), an external size of 2165 × 828 × 349 mm and a passage size of 2017 × 720 × 349 mm. Working temperature is -20°C to +65°C with 99% non-condensing humidity, and input is AC 100V–240V / 50–60Hz.
The unit provides 0–400 adjustable sensitivity and 0–50 volume, 0–3 second alarm volume and 15 different alarm tones, detecting ferrous metals. It includes an infrared sensor for pass count and alarm count, a high-brightness LED digital zone display with glowing LED indication from top to bottom on the single zone, and easy fixing of cross beams with a side-door DFMD controller.
What Is D270-1-IP54?
D270-1-IP54 is an IP54-based single-zone walk-through metal detector from eSSL.
Software & Integration
The D270-1-IP54 supports infrared pass and alarm counting and can be paired with compatible access-control and entrance-automation systems at screening points. Integrates with MegaMind Attendance and MegaMind HRMS.
Applications
Typical deployments for the D270-1-IP54: - Entry screening - Corporate premises - Government buildings - Event security - Factories and industrial sites - Schools and institutions - Metro stations - Theatres and public venues
Ideal for — D270-1-IP54
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for D270-1-IP54 (D270-1-IP54).
Detection
| Zones | Single zone |
|---|---|
| Detection | Ferrous metals |
| Alarm Tones | 15 different tones |
| Working Principle | Electromagnetic |
Physical
| External Size | 2165 × 828 × 349 mm |
|---|---|
| Passage Size | 2017 × 720 × 349 mm |
| IP Rating | IP54 |
| Net Weight (kg) | 21 kg |
Additional Specifications
| Zone Configuration | Single zone |
|---|---|
| Sensitivity Adjustable | 0–400 |
| Volume Adjustable | 0–50 |
| Alarm Volume | 0–3 sec |
| Type | Single-zone walk-through metal detector |
| Material | ABS (Acrylonitrile Butadiene Styrene) raw materials |
| Working Temperature | -20°C to +65°C |
| Input | AC 100V–240V / 50–60Hz |
| Wi-Fi | No |
| TCP/IP | No |
| LAN Interface | No |
| USB Port | No |
| Wiegand Interface | No |
| PoE Support | No |
| Battery Backup | No |
| Frequency | 0–100 |
| Zone Count | Single zone |
| Metal Detection Threshold | Ferrous metals <75 gm |
| Detection Zones | 1 |
| Ip Rating Published | 54 [Dust proof coating] |
| Working Humidity | 99%, non-condensing |
| Input Voltage | AC 100–240V |
| Input Frequency | 50–60Hz |
| Product Colour | Matte Black |
| Gross Weight | 27 kg |
| Sensitivity Range | 0–400 |
| Volume Range | 0–50 |
| Alarm Duration | 0–3 sec |
| Pass Count Sensor | Infrared |
| Alarm Count Sensor | Infrared |
| Zone Indicator | Yes (top-to-bottom LED on single zone) |
| Installation Type | 2 doors + cross beam |
How to choose the right DFMD device
Every dfmd requirement is different. Before you buy D270-1-IP54, compare these points — they are the same checks our engineers use when recommending dfmd attendance and access solutions to Indian businesses.
What to look for in a DFMD
- Compare zones against your actual workload
- Compare sensitivity against your actual workload
- Compare detection against your actual workload
- Compare alarm tones against your actual workload
- Compare working principle against your actual workload
- Compare external size against your actual workload
- Compare passage size against your actual workload
- Compare ip rating against your actual workload
Service, warranty & software
- Warranty: 1 Year — confirm claim process and turnaround
- Works with MegaMind Attendance software for shifts, payroll export and reports
- Pan-India installation, training and AMC support from certified engineers
- Availability: On Request — confirm lead time with your quote
Connectivity & integration
- API and SDK support for custom HRMS, ERP and payroll integration
Applications — D270-1-IP54
Industries and use-cases where the D270-1-IP54 is commonly deployed.
- Entry screening
- Corporate premises
- Government buildings
- Event security
- Factories and industrial sites
- Schools and institutions
- Metro stations
- Theatres and public venues
Documents & Downloads — D270-1-IP54
Compatibility — D270-1-IP54
- MegaMind Attendance
- MegaMind HRMS
