AI-FACE-ARION
Model: AiFace-Arion · SKU: MM-eSSL-ARION
Brand: eSSL · Warranty: 1 Year
The AI-FACE-ARION (AiFace-Arion) is a face, fingerprint, card, password face terminal from eSSL — The eSSL AI-FACE-ARION is a multi-biometric face recognition attendance and access-control terminal supporting 6,000 face templates, 6,000 fingerprints, 10,000 cards and 200,000 transactions. It features a 5-inch display, 2MP WDR low-light camera, 1GHz dual-core CPU, 1GB RAM, 8GB ROM, facial recognition below 1 second and fingerprint recognition below 0.3 second.
- Authentication
- Face, Fingerprint, Card, Password
- Brand
- eSSL
- Product type
- Standalone Product
- Sold by
- MegaMind Technosoft
- Category
- Face
- Face capacity
- 6,000
- Fingerprint capacity
- 6,000
- Card capacity
- 10,000
- Transactions
- 200,000
- Recognition speed
- <1 sec face / <0.3 sec fingerprint
- Connectivity
- Wi-Fi · TCP/IP · Wiegand
- Availability
- In Stock
- Warranty
- 1 Year
Key Features — AiFace-Arion
- Visible-light facial recognition
- Fingerprint, card and password authentication
- Virtual keypad
- 6,000 face templates, 6,000 fingerprints, 10,000 cards
- 200,000 transactions
- 5-inch display
- 2MP WDR low-light camera
- 1GHz dual-core CPU, 1GB RAM, 8GB ROM
- Facial verification <1 sec
- Fingerprint verification <0.3 sec
- Face recognition distance 1–100 cm
- 125 kHz Proximity ID card standard
- Optional MIFARE 13.56 MHz, HID Prox and HID iClass
- TCP/IP, Wiegand in/out, RS485 and Wi-Fi
- Electromagnetic/electric lock, door sensor, exit button and alarm output
- eTimeTrackLite software
Product Overview
The eSSL AI-FACE-ARION is designed as a high-capacity multi-biometric terminal for employee attendance and access control. It combines facial recognition, fingerprint, card and virtual-keypad password authentication in a single device.
The device supports 6,000 face templates, 6,000 fingerprint templates, 10,000 cards and 200,000 transaction records. Its hardware platform includes a 1GHz dual-core CPU, 1GB RAM, 8GB ROM and a 2MP WDR low-light camera.
eSSL publishes facial recognition speed below 1 second and fingerprint verification below 0.3 second. Facial recognition distance is listed as 1 cm to 100 cm, with facial FAR ≤0.01% and facial FRR ≤0.02%.
The terminal supports Proximity ID cards at 125 kHz, optional MIFARE at 13.56 MHz, optional HID Prox and HID iClass. Communication includes TCP/IP, Wiegand Input/Output, RS485 and Wi-Fi. Its access-control interface provides electromagnetic/electric lock, door sensor, exit button and alarm output.
What Is AI-FACE-ARION?
eSSL AI-FACE-ARION is a multi-biometric face and fingerprint time attendance and access-control terminal combining facial recognition, fingerprint, card and virtual-keypad password authentication in a single device.
Software & Integration
The ARION is supported by eTimeTrackLite software. MegaMind Technosoft also configures it with MegaMind Attendance, MegaMind HRMS and MegaMind Payroll software, and deploys it within face recognition attendance systems.
Applications
Typical deployments for the AI-FACE-ARION: - Biometric Employee Attendance - Face & Fingerprint Attendance - Access Control - Controlled Door Access - Office Attendance - Workforce Attendance - Multi-shift attendance sites - Visitor/Staff Authentication
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for AI-FACE-ARION (AiFace-Arion).
General
| Model | AiFace-Arion |
|---|---|
| Device Type | Face + fingerprint + card + password biometric terminal |
| Display | 5" |
| Recognition Speed | <1 sec face / <0.3 sec fingerprint |
Biometric
| Face Capacity (templates) | 6,000 |
|---|---|
| Fingerprint Capacity (templates) | 6,000 |
| Card Capacity (cards) | 10,000 |
| Transaction Capacity (logs) | 2,00,000 |
Connectivity
| TCP/IP | Yes |
|---|---|
| Wi-Fi | Yes |
| USB | No |
| Wiegand | Yes |
| PoE | No |
Power
| Power | DC 12V / 3A |
|---|---|
| Battery Backup | No |
Environment
| Operating Temperature | -10°C to 45°C |
|---|
Additional Specifications
| Operating System | Linux |
|---|---|
| CPU / RAM / ROM | 1GHz dual core / 1GB / 8GB |
| Authentication | Face / Fingerprint / Card / Password |
| Fingerprint Verification Speed | <0.3 sec |
| Facial Recognition Distance | 1–100 cm |
| Facial FAR / FRR | ≤0.01% / ≤0.02% |
| Fingerprint FAR / FRR | ≤0.0001% / ≤0.01% |
| Optional Card | MIFARE @ 13.56 MHz |
| Optional HID | HID Prox / HID iClass |
| Communication | TCP/IP, Wiegand Input/Output, RS485, Wi-Fi |
| Access Control | Electromagnetic lock / electric lock |
| Door Sensor / Exit Button | Yes / Yes |
| Operating Humidity | 10%–90% RH non-condensing |
| Software | eTimeTrackLite |
| Camera | 2MP WDR low-light |
| Cpu | 1GHz dual core |
| Rs485 | Yes |
| Humidity | 10%–90% RH non-condensing |
| LAN Interface | No |
| Facial Recognition Speed | <1 sec |
| Fingerprint Recognition Speed | <0.3 sec |
| Face Distance | 1–100 cm |
| Os | Linux |
| Ram | 1GB |
| Rom | 8GB |
| Standard Card | Proximity ID card @ 125 kHz |
| Optional Cards | MIFARE 13.56 MHz, HID Prox, HID iClass |
| Alarm Output | Yes |
How to choose the right Face device
Every face requirement is different. Before you buy AiFace-Arion, compare these points — they are the same checks our engineers use when recommending face attendance and access solutions to Indian businesses.
Size it to your site
- Face capacity of 6,000 templates — size it against your head count plus future growth
- Fingerprint capacity of 6,000 templates
- Card capacity of 10,000 cards
- Transaction capacity of 200,000 logs — enough for daily punches across sites
- Recognition speed of <1 sec face / <0.3 sec fingerprint
- Supported methods: face, fingerprint, card, password — pick the method your employees will actually use
What to look for in a Face
- Compare device type against your actual workload
- Compare display against your actual workload
- Compare recognition speed against your actual workload
- Compare face capacity (templates) against your actual workload
- Compare fingerprint capacity (templates) against your actual workload
- Compare card capacity (cards) against your actual workload
- Compare transaction capacity (logs) against your actual workload
- Check TCP/IP is built in if your site needs it
Service, warranty & software
- Warranty: 1 Year — confirm claim process and turnaround
- Works with MegaMind Attendance software for shifts, payroll export and reports
- Pan-India installation, training and AMC support from certified engineers
- Availability: In Stock — confirm lead time with your quote
Connectivity & integration
- Wi-Fi connectivity for wireless network deployment
- TCP/IP Ethernet port for robust network communication
- Wiegand interface for connecting external card readers or door controllers
- API and SDK support for custom HRMS, ERP and payroll integration
Applications — AiFace-Arion
Industries and use-cases where the AI-FACE-ARION is commonly deployed.
- Biometric Employee Attendance
- Face & Fingerprint Attendance
- Access Control
- Controlled Door Access
- Office Attendance
- Workforce Attendance
- Multi-shift attendance sites
- Visitor/Staff Authentication
Documents & Downloads — AiFace-Arion
Compatibility — AiFace-Arion
- MegaMind Attendance
- MegaMind HRMS
