AI-FACE MARS+QR
Model: Aiface Mars+QR · SKU: MM-eSSL-MARS-QR
Brand: eSSL · Warranty: 1 Year
The AI-FACE MARS+QR (Aiface Mars+QR) is a face, qr code, card, password face terminal from eSSL — The eSSL AI-FACE MARS+QR is a facial recognition time attendance and access-control terminal supporting face, QR code, card and password authentication. It provides 6,000 face templates, 10,000 cards and 200,000 transactions, with a 5-inch touch screen, 900MHz dual-core CPU, 1GB RAM, 8GB Flash, 2MP WDR low-light camera and barcode scanning.
- Authentication
- Face, QR Code, Card, Password
- Brand
- eSSL
- Product type
- Standalone Product
- Sold by
- MegaMind Technosoft
- Category
- Face
- Face capacity
- 6,000
- Card capacity
- 10,000
- Transactions
- 200,000
- Recognition speed
- ≤1 sec
- Connectivity
- Wi-Fi · TCP/IP · Wiegand
- Availability
- In Stock
- Warranty
- 1 Year
Key Features — Aiface Mars+QR
- Visible-light facial recognition
- QR-code, card and password authentication
- 6,000 face templates
- 10,000 card templates
- 200,000 transaction capacity
- 5-inch touch screen
- 900MHz dual-core CPU, 1GB RAM, 8GB Flash
- 2MP WDR low-light camera
- Barcode scanning
- Facial recognition speed ≤1 sec
- QR Code, PDF417, Data Matrix and MicroPDF417 support
- TCP/IP, optional Wi-Fi, Wiegand In/Out and RS485
- Electromagnetic lock, electric lock, door sensor, exit button, auxiliary input and alarm output
- Optional 13.56MHz IC card
- eTimeTrackLite and eBioServer
Product Overview
The eSSL AI-FACE MARS+QR is designed for organizations that need contactless facial recognition together with QR-code based authentication. The device combines facial recognition, QR/barcode scanning, card authentication and password verification in a single terminal.
The terminal supports 6,000 face templates, 10,000 card templates and 200,000 transactions. Its hardware platform includes a 900MHz dual-core CPU, 1GB RAM and 8GB Flash, along with a 2MP WDR low-light camera and barcode-scanning capability.
Facial recognition speed is specified as ≤1 second. Communication includes TCP/IP, optional Wi-Fi, Wiegand Input/Output and RS485. The access-control interface supports electromagnetic/electric lock, door sensor, exit button, auxiliary input and auxiliary alarm output.
The QR sensor supports QR Code, PDF417, Data Matrix and MicroPDF417, giving the product a broader 2D-code authentication capability than a standard face/card terminal.
What Is AI-FACE MARS+QR?
eSSL AI-FACE MARS+QR is a facial recognition time attendance and access-control system with QR-code, card and password authentication, designed for contactless face attendance combined with QR-code based authentication.
Software & Integration
The MARS+QR is supported by eTimeTrackLite and eBioServer. MegaMind Technosoft also configures it with MegaMind Attendance and MegaMind HRMS software.
Applications
Typical deployments for the AI-FACE MARS+QR: - Face Recognition Attendance - QR Attendance - Contactless Employee Attendance - Visitor/Staff Authentication - Access Control - QR-Based Door Authentication - Workforce Attendance - Secure Office Entry - Institutional Access Management
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for AI-FACE MARS+QR (Aiface Mars+QR).
General
| Model | Aiface Mars+QR |
|---|---|
| Device Type | Face + QR code + card + password time attendance & access control system |
| Display | 5" touch screen |
| Recognition Speed | ≤1 sec |
Biometric
| Face Capacity (templates) | 6,000 |
|---|---|
| Card Capacity (cards) | 10,000 |
| Transaction Capacity (logs) | 2,00,000 |
Connectivity
| TCP/IP | Yes |
|---|---|
| Wi-Fi | Yes |
| USB | No |
| Wiegand | Yes |
| PoE | No |
Power
| Power | DC 12V, 3A |
|---|---|
| Battery Backup | No |
Environment
| Operating Temperature | -10°C to 45°C |
|---|
Additional Specifications
| Face Template Capacity | 6,000 |
|---|---|
| Card Template Capacity | 10,000 |
| Operating System | Linux |
| CPU / RAM / Flash | 900MHz dual core / 1GB / 8GB |
| Authentication | Face / QR Code / Card / Password |
| QR Sensor | QR Code / PDF417 / Data Matrix / MicroPDF417 |
| Communication | TCP/IP, Wiegand Input/Output, RS485 |
| Optional Communication | Wi-Fi |
| Optional Card | 13.56MHz IC card (MF) |
| Access Control | Electromagnetic lock / electric lock |
| Door Sensor / Exit Button | Yes / Yes |
| Auxiliary Input / Alarm Output | Yes / Yes |
| Power Supply | DC 12V, 3A |
| Operating Humidity | 10%–90% |
| Camera | 2MP WDR low-light |
| Cpu | 900MHz dual core |
| Barcode Scanning | Yes |
| Rs485 | Yes |
| Humidity | 10%–90% |
| LAN Interface | No |
| Facial Recognition Speed | ≤1 sec |
| Qr Formats | QR Code, PDF417, Data Matrix, MicroPDF417 |
| Os | Linux |
| Ram | 1GB |
| Flash | 8GB |
| Optional Cards | 13.56MHz IC/MF |
Access Control Software & Features
| Supported Software | eTimeTrackLite, eBioServer |
|---|
How to choose the right Face device
Every face requirement is different. Before you buy Aiface Mars+QR, compare these points — they are the same checks our engineers use when recommending face attendance and access solutions to Indian businesses.
Size it to your site
- Face capacity of 6,000 templates — size it against your head count plus future growth
- Card capacity of 10,000 cards
- Transaction capacity of 200,000 logs — enough for daily punches across sites
- Recognition speed of ≤1 sec
- Supported methods: face, qr code, card, password — pick the method your employees will actually use
What to look for in a Face
- Compare device type against your actual workload
- Compare display against your actual workload
- Compare recognition speed against your actual workload
- Compare face capacity (templates) against your actual workload
- Compare fingerprint capacity (templates) against your actual workload
- Compare card capacity (cards) against your actual workload
- Compare transaction capacity (logs) against your actual workload
- Check TCP/IP is built in if your site needs it
Service, warranty & software
- Warranty: 1 Year — confirm claim process and turnaround
- Works with MegaMind Attendance software for shifts, payroll export and reports
- Pan-India installation, training and AMC support from certified engineers
- Availability: In Stock — confirm lead time with your quote
Connectivity & integration
- Wi-Fi connectivity for wireless network deployment
- TCP/IP Ethernet port for robust network communication
- Wiegand interface for connecting external card readers or door controllers
- API and SDK support for custom HRMS, ERP and payroll integration
Applications — Aiface Mars+QR
Industries and use-cases where the AI-FACE MARS+QR is commonly deployed.
- Face Recognition Attendance
- QR Attendance
- Contactless Employee Attendance
- Visitor/Staff Authentication
- Access Control
- QR-Based Door Authentication
- Workforce Attendance
- Secure Office Entry
- Institutional Access Management
Documents & Downloads — Aiface Mars+QR
Compatibility — Aiface Mars+QR
- MegaMind Attendance
- MegaMind HRMS
