FL500
Model: FL500 · SKU: MM-eSSL-FL500
Brand: eSSL · Warranty: 1 Year
The FL500 (FL500) is a fingerprint, face, password, card fingerprint door locks terminal from eSSL — The eSSL FL500 is a 5-in-1 smart door lock for wooden doors, combining fingerprint, palm, password, face and card authentication. It supports 100 fingerprints, 20 palms, 20 faces, 50 passwords and 50 cards, with Wi-Fi connectivity through the Tuya Smart App and a rechargeable 5000mAh lithium battery.
- Authentication
- Fingerprint, Face, Password, Card
- Brand
- eSSL
- Product type
- Standalone Product
- Sold by
- MegaMind Technosoft
- Category
- Fingerprint Door Locks
- Face capacity
- 20
- Fingerprint capacity
- 100
- Card capacity
- 50
- Connectivity
- Wi-Fi
- Availability
- In Stock
- Warranty
- 1 Year
Key Features — FL500
- 5-in-1 smart access system
- Fingerprint authentication
- Palm authentication
- Face authentication
- Password authentication
- Card authentication
- 100 fingerprint capacity
- 20 palm capacity
- 20 face capacity
- 50 password capacity
- 50 card capacity
- Password length 6–12
- Wooden-door support
- 45–120 mm door thickness
- Aluminum-alloy construction
- Bronze finish
- 5000mAh rechargeable lithium battery
- Low-battery reminder
- Trial-and-error alarm
- One-click locking
- Touch keypad
- Voice guidance
- Single unlocking mode
- Combined unlocking mode
- Child-safety lock
- Passage-way option
- Wi-Fi
- Tuya Smart App / Smart Life Smart Things
- Real-time access logs through mobile app
- Emergency key
- Single-latch trio bolt
Product Overview
The FL500 is a multi-method smart fingerprint door lock designed for wooden doors with a published thickness range of 45–120 mm. eSSL identifies the product as a 5-in-1 access system, with fingerprint, palm, password, face and card credential methods.
The lock uses an aluminum-alloy body and has separate front and rear panel dimensions: 413 × 67.8 × 55 mm and 440 × 73.4 × 32 mm respectively. The published colour is Bronze.
The lock stores 100 fingerprints, 20 palms, 20 faces, 50 passwords and 50 cards. Password length is specified as 6–12 characters/digits in the current product specification.
Power comes from a 5000mAh lithium battery. The current eSSL page also specifies low-battery reminder, trial-and-error alarm and one-click locking.
The FL500 provides a touch keypad and voice guidance. Unlocking can be configured in single mode or combined mode. A child-safety lock and passage-way option are also published.
For remote management, the product supports the Tuya Mobile App / Smart Life Smart Things ecosystem over Wi-Fi. eSSL states that real-time access logs can be viewed through the mobile application.
Mechanical construction includes a single-latch trio bolt and rechargeable-battery design.
What Is FL500?
FL500 is an eSSL 5-in-1 smart fingerprint door lock for wooden doors.
Software & Integration
Wi-Fi connectivity through the Tuya Smart App / Smart Life Smart Things platform is published, including real-time access logs and operating/monitoring functions per the product page. Emergency key and one-click locking are supported. Aligns with MegaMind Attendance and MegaMind HRMS deployments.
Applications
Typical deployments for the FL500: - Wooden doors - Residential and light-commercial smart door access
Ideal for — FL500
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for FL500 (FL500).
Access Methods
| Fingerprint Capacity (templates) | 100 |
|---|---|
| Password Capacity (codes) | 50 |
| Card Capacity (cards) | 50 |
Power & Installation
| Battery | 5000mAh lithium battery |
|---|---|
| Door Thickness | 45–120 mm |
| Material | Aluminum alloy |
Additional Specifications
| Emergency Key | Yes |
|---|---|
| Keypad | Touch |
| Connectivity | Wi-Fi |
| Alarm | Low Battery / Trial and Error / One-Click Locking |
| Type | 5-in-1 smart fingerprint door lock |
| Door Type | Wooden doors |
| Palm Capacity | 20 |
| Face Capacity | 20 |
| Password Length | 6–12 |
| Wi-Fi | Yes |
| Mobile App | Tuya Smart App / Smart Life Smart Things |
| Service Life | >100,000 |
| Front Panel | 413 × 67.8 × 55 mm |
| Back Panel | 440 × 73.4 × 32 mm |
| Colour | Bronze |
| Front Panel Size | 413 × 67.8 × 55 mm |
| Back Panel Size | 440 × 73.4 × 32 mm |
| Fingerprint Enabled | Yes |
| Palm Enabled | Yes |
| Face Enabled | Yes |
| Password Enabled | Yes |
| Card Enabled | Yes |
| Manual Key Enabled | Yes — emergency key |
| Wifi Enabled | Yes |
| Real Time Access Logs | Yes, through mobile app |
| Unlocking Mode | Single mode / combined mode |
| Child Safety Lock | Yes |
| Passage Way Option | Yes |
| Touch Keypad | Yes |
| Voice Guidance | Yes |
| Battery Type | 5000mAh rechargeable lithium battery |
| Low Battery Reminder | Yes |
| Trial Error Alarm | Yes |
| One Click Locking | Yes |
| Bolt | Single-latch trio bolt |
| Operating Temperature | -15°C to +70°C |
| Working Humidity | 20%–90% |
How to choose the right Fingerprint Door Locks device
Every fingerprint door locks requirement is different. Before you buy FL500, compare these points — they are the same checks our engineers use when recommending fingerprint door locks attendance and access solutions to Indian businesses.
Size it to your site
- Face capacity of 20 templates — size it against your head count plus future growth
- Fingerprint capacity of 100 templates
- Card capacity of 50 cards
- Supported methods: fingerprint, face, password, card — pick the method your employees will actually use
What to look for in a Fingerprint Door Locks
- Compare unlock methods against your actual workload
- Compare fingerprint capacity (templates) against your actual workload
- Compare password capacity (codes) against your actual workload
- Compare card capacity (cards) against your actual workload
- Compare battery against your actual workload
- Compare power supply against your actual workload
- Compare door thickness against your actual workload
- Compare recognition speed against your actual workload
Service, warranty & software
- Warranty: 1 Year — confirm claim process and turnaround
- Works with MegaMind Attendance software for shifts, payroll export and reports
- Pan-India installation, training and AMC support from certified engineers
- Availability: In Stock — confirm lead time with your quote
Connectivity & integration
- Wi-Fi connectivity for wireless network deployment
- API and SDK support for custom HRMS, ERP and payroll integration
Applications — FL500
Industries and use-cases where the FL500 is commonly deployed.
- Wooden doors
- Residential and light-commercial smart door access
Documents & Downloads — FL500
Compatibility — FL500
- MegaMind Attendance
- MegaMind HRMS
