Panasonic VL-VC3900BX-E IP Video Door Phone Lobby Station with 5.5-Inch Screen
Model: VL-VC3900BX-E
Brand: Panasonic
The Panasonic VL-VC3900BX-E IP Video Door Phone Lobby Station with 5.5-Inch Screen (VL-VC3900BX-E) is a sip video door phones terminal from Panasonic — Panasonic VL-VC3900BX-E is an IP video door phone lobby station with a 5.5-inch colour display, 2MP CMOS camera, leave-message and tamper alert functions, electric lock release and IP54/IK07 aluminium housing.
- Brand
- Panasonic
- Product type
- Standalone Product
- Sold by
- MegaMind Technosoft
- Category
- SIP Video Door Phones
- Availability
- On Request
Key Features — VL-VC3900BX-E
- 5.5-inch colour lobby display (480 x 272) in a slim flush-mount panel
- 2MP 1/2.7-inch CMOS camera with 3.6 mm lens and white-LED colour night vision
- Leave message function so visitors can record a message when unanswered
- Tamper alerts notify security staff if the lobby panel is disturbed
- One electric lock release output for turnstiles, gates or door strikes
- IP54 weatherproof and IK07 impact-resistant aluminium with tempered glass
- Hands-free H.264 video and G.711 audio over standard IP networks
- Flush mounted and powered through the VL-PC3800BX-E power distributor
Product Overview
The Panasonic VL-VC3900BX-E is an IP video door phone lobby station with a 5.5-inch colour display, 2MP CMOS camera, white-LED night vision, leave-message and tamper alerts, one electric lock release and an IP54/IK07 aluminium flush-mount body.
What is the Panasonic VL-VC3900BX-E IP Video Door Phone Lobby Station with 5.5-Inch Screen?
The VL-VC3900BX-E is the entrance terminal of a Panasonic IP video door phone system. Visitors call apartments or offices from the lobby, see themselves verified on the network monitor side, and can leave a recorded message; the panel also releases the entrance lock and reports tampering.
Who is it for?
Built for apartment tower lobbies, multi-tenant office buildings, gated community visitor portals, hospital and institutional entrances and mixed-use commercial complexes that require directory calling and visitor verification.
How to Choose
Confirm the number of apartments or tenants to be hosted, plan the VL-PC3800BX-E power distributor and Cat5e/Cat6 uplink in the riser, decide whether a flush mounting box is available in the stone or drywall finish, and confirm the entrance lock or turnstile to be released.
Applications
Deployment applications for the VL-VC3900BX-E include:
- High-rise apartment entrance lobbies with resident directories
- Multi-tenant office building reception portals
- Gated community main and visitor entrances
- Hospital, hotel and institutional campus entrances
Ideal for — VL-VC3900BX-E
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for Panasonic VL-VC3900BX-E IP Video Door Phone Lobby Station with 5.5-Inch Screen (VL-VC3900BX-E).
Camera & Display
| Display | 5.5-inch wide colour display (480 x 272 pixels) |
|---|---|
| Night Vision | White coloured LED lights (min 0.01 lx within approx. 50 cm of the lens) |
Network & Power
| Dimensions | Approx. 386 x 166 x 52 mm (H x W x D, excluding protruding sections) |
|---|
Hardware & Controller Interfaces
| Operating System | Linux |
|---|
Additional Specifications
| Station Type | Lobby Station for IP VDP systems |
|---|---|
| Display Language | English, Chinese, Vietnamese and Indonesian |
| Talking Method | Hands-free |
| Camera Sensor | 2.0 MP CMOS, 1/2.7-inch sensor, 3.6 mm EFL |
| Viewing Angle | Horizontally: approx. 76°, Vertically: approx. 50° |
| Video Audio Format | Video: H.264, Audio: G.711 |
| Network Interface | RJ45, 10BASE-T/100BASE-TX (Auto MDI/MDI-X) |
| Network Protocol | IPv4, TCP, ICMP, UDP, RTSP, HTTP, DNS, RTP, RTMP, ARP, NTP |
| Wiring | UTP (Cat 5e or higher) |
| Expanded Interface | Support for electric lock releasing (entrance unlocking) x 1 |
| Power Source | Power distributor VL-PC3800BX-E (sold separately) |
| Power Consumption | Standby: 2.5 W, Operating: 3.5 W |
| Protection Rating | IP54 ingress protection, IK07 impact protection |
| Installation | Flush mount |
| External Material | Aluminium + tempered glass |
| Colour | Black |
| Cpu | ARM Cortex-A7 |
| Memory | RAM 64 MB (512 Mbit), Flash 16 MB (128 Mbit) |
| Weight | Approx. 1600 g |
| Operating Temperature | -40°C to +70°C |
| Operating Humidity | Up to 90% RH (non-condensing) |
| Documents | Video Intercom Solution brochure, VA514 quick guide and installation guide |
How to choose the right SIP Video Door Phones device
Every sip video door phones requirement is different. Before you buy VL-VC3900BX-E, compare these points — they are the same checks our engineers use when recommending sip video door phones attendance and access solutions to Indian businesses.
What to look for in a SIP Video Door Phones
- Compare display against your actual workload
- Compare image sensor against your actual workload
- Compare monitor resolution against your actual workload
- Compare night vision against your actual workload
- Compare ip rating against your actual workload
- Compare ik rating against your actual workload
- Compare wi-fi against your actual workload
- Compare power against your actual workload
Service, warranty & software
- Warranty: 1 Year — confirm claim process and turnaround
- Works with MegaMind Attendance software for shifts, payroll export and reports
- Pan-India installation, training and AMC support from certified engineers
- Availability: On Request — confirm lead time with your quote
Connectivity & integration
- API and SDK support for custom HRMS, ERP and payroll integration
Applications — VL-VC3900BX-E
Industries and use-cases where the Panasonic VL-VC3900BX-E IP Video Door Phone Lobby Station with 5.5-Inch Screen is commonly deployed.
- High-rise apartment entrance lobbies
- Multi-tenant office building reception portals
- Gated community main and visitor entrances
- Hospital, hotel and institutional campus entrances
