Panasonic VL-SA71 7-Inch Analog Video Door Phone Kit
Model: VL-SA71
Brand: Panasonic
The Panasonic VL-SA71 7-Inch Analog Video Door Phone Kit (VL-SA71) is a video door phones terminal from Panasonic — Panasonic VL-SA71 is an analog video door phone kit featuring a 7-inch capacitive touchscreen monitor (1024x600), 2MP HD outdoor camera, IP65/IK08 rating, and multi-unit support.
- Brand
- Panasonic
- Product type
- Bundle
- Sold by
- MegaMind Technosoft
- Category
- Video Door Phones
- Availability
- On Request
Key Features — VL-SA71
- Complete video intercom kit: 7-inch touchscreen monitor and 2MP outdoor camera station
- 7-Inch Colour capacitive touchscreen with high 1024 x 600 resolution
- High-definition door camera with 2MP 1/3" CMOS sensor and 120° diagonal viewing angle
- Scalable architecture supporting up to 4 indoor monitors and 2 outdoor door units
- Colour night vision with integrated high-output white LED illumination
- Weatherproof IP65 and robust IK08 vandal-resistant outdoor station
- Integrated electric door lock relay output (NO/COM/NC) for gates and doors
- Analog CCTV camera integration support for enhanced perimeter surveillance
What's in the box — VL-SA71
The Panasonic VL-SA71 7-Inch Analog Video Door Phone Kit is supplied with the components below.
| Component | Type | Qty | Required |
|---|---|---|---|
| VL-VA502SX Door Camera (VL-VA502SX) | — | 1 | |
| VL-MA71SX Indoor Monitor (VL-MA71SX) | — | 1 |
Product Overview
The Panasonic VL-SA71 is a 7-inch capacitive touchscreen analog video door phone system featuring a 2MP high-definition outdoor camera, multi-room expandability (up to 4 monitors & 2 door stations), IP65/IK08 rating, and electric door lock integration.
What is the Panasonic VL-SA71 7-Inch Analog Video Door Phone Kit?
The VL-SA71 is a complete hardwired video intercom kit comprising an indoor room display station and an outdoor camera call unit. When visitors press the doorbell, the indoor monitor rings, displaying live color video so residents can speak hands-free and unlock the gate safely.
Who is it for?
Ideal for independent villas, row houses, builder floors, duplex apartments, and small commercial clinics or offices looking for a dependable, high-definition intercom without complex network setup.
How to Choose
Confirm the distance between your gate and monitor location (standard 4-wire cabling applies), determine if additional extension monitors are needed for upstairs bedrooms, and verify your electric door lock type.
Applications
Typical deployment scenarios for the VL-SA71 include:
- Standalone villas and independent bungalows
- Multi-floor residential builder floors
- Private duplex and triplex apartments
- Small offices, clinics, and consultancy reception doors
Technical Specifications
Detailed hardware, electrical, network, and operational specifications for Panasonic VL-SA71 7-Inch Analog Video Door Phone Kit (VL-SA71).
Camera & Display
| Monitor Resolution | 1024 x 600 pixels |
|---|---|
| Night Vision | Colour night vision with white LED lights (min 1 lx at 50 cm) |
Additional Specifications
| Kit Contents | Main Indoor Monitor Station (VL-MA71) + Outdoor Door Station (VL-VA502) |
|---|---|
| Monitor Display | 7-inch wide colour capacitive touchscreen (approx. 17.8 cm) |
| Talking Method | Hands-free full duplex intercom |
| Camera Sensor | 1/3" CMOS with 2MP Lens |
| Camera Viewing Angle | Diagonally: 120°, Horizontally: 90°, Vertically: 66° |
| Lock Connection Relay | 1 Relay (NO/COM/NC) for electric door strike or magnetic lock |
| System Expandability | Up to 4 indoor monitors + 2 outdoor door stations + analog CCTV camera |
| Outdoor Protection | IP65 weatherproof, IK08 vandal impact rating |
| Installation Method | Monitor: Wall mount (bracket supplied); Door station: Surface mount (base supplied) |
| Power Source | DC 14.5V 1A (power supply included), door station powered by monitor |
| Power Consumption | Standby: <3.0 W, Operating: <10.0 W |
| Dimensions Monitor | 140 x 190 x 22 mm (H x W x D, excluding protruding sections) |
| Dimensions Door | 150 x 95 x 41 mm (H x W x D, excluding protruding sections) |
| Weight Monitor | 320 g |
| Weight Door | 228 g |
| Operating Temperature | -20°C to +70°C (both monitor and door station) |
| Operating Humidity | 10% to 90% RH (non-condensing) |
| Display Language | English, Arabic |
How to choose the right Video Door Phones device
Every video door phones requirement is different. Before you buy VL-SA71, compare these points — they are the same checks our engineers use when recommending video door phones attendance and access solutions to Indian businesses.
What to look for in a Video Door Phones
- Compare display against your actual workload
- Compare image sensor against your actual workload
- Compare monitor resolution against your actual workload
- Compare night vision against your actual workload
- Compare ip rating against your actual workload
- Compare ik rating against your actual workload
- Compare wi-fi against your actual workload
- Compare power against your actual workload
Service, warranty & software
- Warranty: 1 Year — confirm claim process and turnaround
- Works with MegaMind Attendance software for shifts, payroll export and reports
- Pan-India installation, training and AMC support from certified engineers
- Availability: On Request — confirm lead time with your quote
Connectivity & integration
- API and SDK support for custom HRMS, ERP and payroll integration
Applications — VL-SA71
Industries and use-cases where the Panasonic VL-SA71 7-Inch Analog Video Door Phone Kit is commonly deployed.
- Independent villas and bungalows
- Builder floors and duplex homes
- Apartments and row houses
- Small offices and clinics
